PostgreSQL v14 has new connection statistics in
pg_stat_database. In this article, I want to explore one application for them: estimating the correct size for a connection pool.
New connection statistics in v14
Commit 960869da080 introduced some new statistics to
session_time: total time spent by sessions in the database
active_time: time spent executing SQL statements in the database
idle_in_transaction_time: time spent idle in a transaction in the database
sessions: total number of sessions established to the database
sessions_abandoned: number of sessions to the database that were terminated by lost client connections
sessions_fatal: number of sessions to the database terminated by fatal errors
sessions_killed: number of sessions to the database killed by an operator
Some applications are obvious: for example, you may want to keep the number of fatal errors or operator interventions low, or you may want to fix your application to properly close database connections.
But I want to show you another, less obvious, application for these statistics.
Connection pooling modes
In the following, I assume that the application connects to the database with a single database user. That means that there will be one connection pool per database.
If you use session level connection pooling, a client gets a session from the pool for the whole duration of the database session. In this case, sizing the connection pool is simple: the pool has to be large enough to accommodate the maximum number of concurrent sessions. The number of connections to a database is available in
pg_stat_database, and many monitoring systems capture this value. Session level pooling is primarily useful if the client’s database connections are short.
However, it is normally more efficient to use transaction level connection pooling. In this mode, a client gets a session only for the duration of a database transaction. The advantage is that multiple clients can share the same pooled session. Sharing reduces the required number of connections in the pool. Having few database connections is a good thing, because it reduces contention inside the database and limits the danger of overloading the CPU or storage subsystem.
Of course, transaction level pooling makes it more difficult to determine the correct size of the connection pool.
The ideal connection pool size
The ideal size for a connection pool is
- large enough that no client has to wait for a connection during normal load
- as small as possible within the above limit
In my article about
max_connections, I established the following upper limit for the number of connections:
connections < max(num_cores, parallel_io_limit) / (session_busy_ratio * avg_parallelism)
num_coresis the number of cores available
parallel_io_limitis the number of concurrent I/O requests your storage subsystem can handle
session_busy_ratiois the fraction of time that the connection is active executing a statement in the database
avg_parallelismis the average number of backend processes working on a single query.
Using the new statistics to find an upper limit for the connection pool size
Now all these numbers are easy to determine – that is, all except for
With the new database statistics, that task becomes trivial:
SELECT datname, active_time / (active_time + idle_in_transaction_time) AS session_busy_ratio FROM pg_stat_database WHERE active_time > 0;
The new database statistics in PostgreSQL v14 make it easier to get an estimate for the safe upper limit for the size of a connection pool. To learn more about connection pools and authentication, see my post on pgbouncer.
