Be prepared for prepared transactions

12.2018 / Category: / Tags: |

Prepared transactions are disabled in PostgreSQL by default, since the parameter max_prepared_transactions has the default value 0.

You don't need prepared transactions in most cases. However, they can cause nasty problems, so I think that everybody who runs a PostgreSQL database should understand them.

To illustrate these problems, I'll show you how to use prepared transactions to get a PostgreSQL into an inaccessible state.



What are prepared transactions?

Normally, a database transaction that spans multiple statements is ended with COMMIT or ROLLBACK. With prepared transactions, another step is added:

  1. BEGIN or START TRANSACTION: starts a transaction as usual.
  2. PREPARE TRANSACTION 'name': prepares the transaction for commit or rollback and assigns a name to it.
  3. { COMMIT | ROLLBACK } PREPARED 'name': commits or rolls back a previously prepared transaction.



The PREPARE TRANSACTION step performs all actions that may fail during COMMIT. That way, both COMMIT PREPARED and ROLLBACK PREPARED are guaranteed to succeed once a transaction is prepared. Moreover, PREPARE TRANSACTION persists the still open transaction, so that it will survive a crash or server restart.

Once a transaction is prepared, it is complete. Subsequent SQL statements belong to different transactions. You cannot do anything with a prepared transaction except COMMIT PREPARED and ROLLBACK PREPARED.



What is the use of prepared transactions?

Prepared transactions are used to implement “distributed transactions”.
Distributed transactions are transactions that affect more than one data source.
The protocol is as follows:

  1. Start a transaction on all data sources involved in the transaction.
  2. Modify data in the data sources. If there is a problem, ROLLBACK all involved transactions.
  3. Once you are done, PREPARE all involved transactions.
  4. If the PREPARE step fails in any of the transactions, issue ROLLBACK PREPARED everywhere.
  5. If the PREPARE step succeeds everywhere, COMMIT PREPARED all involved transactions.



This so-called “two-phase commit protocol” guarantees that the distributed transaction either succeeds or is rolled back everywhere, leaving the whole system consistent.

To make that works reliably, you need a “distributed transaction manager”.
That is software that keeps track of all distributed transactions, persisting their state to survive crashes and other interruptions.
That way it can complete all interrupted distributed transactions as soon as operation is resumed.



Problems caused by prepared transactions

Normally, no transaction should be in the prepared state for longer than a split second. But software bugs and other disruptions can cause a transaction to remain in the prepared state for a longer time. This causes the problems associated with long running transactions in general:

  • locks that are held for a long time, blocking other sessions and increasing the risk of a deadlock
  • VACUUM cannot clean up dead tuples created after the start of the transaction

These problems are exacerbated by the fact that prepared transactions and their locks stay around even after the database server is restarted.



Implementation details

Preparing a transaction will write a WAL record, so the prepared transaction can be restored during crash recovery. This requires forcing the WAL to disk, just like a normal commit does.

During a checkpoint, the state of the prepared transaction is persisted in a file in the pg_twophase subdirectory of the data directory. The name of the file is the hexadecimal transaction ID.

On startup, all prepared transactions are restored from pg_twophase.

The file is deleted when the prepared transaction is committed or rolled back.



Getting rid of “orphaned” prepared transactions

You can examine all prepared transactions in the PostgreSQL database cluster using the view pg_prepared_xacts.

If a prepared transaction is “orphaned” because the transaction manager failed to close it, you will have to do that manually. Connect to the correct database and run COMMIT PREPARED or ROLLBACK PREPARED.



Locking up a database with prepared transactions

Warning: Don't try this on your production database!

As a database superuser, run the following:

Then disconnect from the database.

pg_authid, the table that contains the database users, is required to authenticate a database session. Since this table is locked by the prepared transaction, all future connection attempts will hang.

Restarting the database won't help, because the prepared transaction will be retained.

Before you read on to the next part that contains the solution, let me invite you to try and get out of this dilemma yourself.



Enter Houdini!

Your first reaction will probably be the same as mine: Start PostgreSQL in single user mode. Alas, no luck:

Single user mode just hangs until I send it a SIGINT by pressing Ctrl+C, which shuts down the server.

But we can easily find a way to recover by reviewing the implementation details above:
571 in hexadecimal is 23b, so while PostgreSQL is shut down, we can remove the prepared transaction as follows:

This will essentially roll back the transaction, and its effects will be undone when PostgreSQL is restarted.




In order to receive regular updates on important changes in PostgreSQL, subscribe to our newsletter, or follow us on Twitter, Facebook, or LinkedIn.

0 0 votes
Article Rating
Subscribe
Notify of
guest
7 Comments
Oldest
Newest Most Voted
Inline Feedbacks
View all comments
glebati
glebati
1 year ago

You can drop all prepared transactions on server start:
var client = DbClient.Make(MainDb);
client.SetCommandText(@"SELECT database, gid FROM pg_prepared_xacts");
var lockedTransactions = client.Select();
foreach(System.Data.DataRow lockedTrans in lockedTransactions.Rows)
{
var db = lockedTrans.ItemArray[0].ToString();
var gid = lockedTrans.ItemArray[1].ToString();
client = DbClient.Make(db);
client.SetCommandText(@$"ROLLBACK PREPARED '{gid}'");
client.Execute();
}

resolving error message "Canceled on conflict out to old pivot"

laurenz
laurenz
1 year ago
Reply to  glebati

That should work if connections to all databases are allowed without a password.
The problem is of course that the database server could have gone down in the middle of a distributed transaction, and other parts of that transactions are already committed elsewhere. The transaction manager should be given a chance to commit the transaction after the server comes up.
Perhaps the best thing would be to have a timeout built into that code.

glebati
glebati
1 year ago
Reply to  laurenz

I don't know 🙁
I am using prepared transaction for making one transaction for query to multiple databases. I have all databases in one machine. (main database and per database for user_projects).

My server can't commit after startup, becouse he lose information (request->ram calculation->db). And get "Canceled on conflict out to old pivot" error on next transaction.

laurenz
laurenz
1 year ago
Reply to  glebati

My server can't commit after startup, becouse he lose information.

Then you shouldn't be using prepared transactions. That is only safe with a transaction manager that has persistent information about all transactions and can clean up after an interruption. If all you ever do after an interruption is to rollback prepared transactions (even if part of the distributed transaction was already committed on a different database!), you would be better off using simple COMMIT in the first place. That would save you the headache of prepared transactions.

Marcus Portmann
Marcus Portmann
2 years ago

This is a very useful post.

Thank you for taking the time to share.

rutuparna andhare
rutuparna andhare
3 years ago

Is this issue still there in Latest postgres 12.4 ?

laurenz
laurenz
3 years ago

Which issue? This is all behaving as it should.
Could you describe your problem?
